Butt-Weld Short 45° Elbow Fittings
Butt-Weld Short 45° Elbows are precision-engineered piping components designed to provide a compact directional change of 45 degrees in piping systems. The short-radius design allows installation in confined spaces while maintaining strength, structural integrity, and flow efficiency. These fittings are ideal for high-pressure and high-temperature applications where space constraints demand a smaller bending radius.
Features of Butt-Weld Short 45° Elbows
Flangeman Steel Worldwide Pvt Ltd’s Butt-Weld Short 45° Elbows are manufactured using advanced hot-forging and butt-weld preparation techniques, ensuring uniform wall thickness and superior mechanical strength. These elbows offer:
Compact design: – Short radius reduces space requirements while ensuring structural integrity
High strength and durability: Suitable for high-pressure and high-temperature environments.
Smooth internal surface: Minimizes turbulence and pressure drop for efficient fluid flow.
Permanent leak-proof joints: Butt-weld connections provide strong, reliable performance
Wide material options:Carbon steel, stainless steel (304/316), and alloy steel for corrosion and chemical resistance.
Standards compliant: Designed per ASME B16.9, ASTM A234 WPB, and MSS-SP-75.
Material Used in Manufacturing Blind Flanges.
Steel
Carbon Steel
Alloy Steel
Duplex & Super Duplex Stainless Steel
Nickel Based Alloys
Applications
Short 45° Butt-Weld Elbows are commonly used in industries requiring compact pipe routing and high reliability, including:
Oil & Gas pipelines and refineries
Petrochemical and chemical processing plants
Refineries
Power Generation
Boiler Systems
Water Treatment Plants
Industrial Process Piping
Marine & Offshore Projects
Standards and Specification
| Parameter | Specification |
|---|---|
| Product Name | Butt-Weld Short 45° Elbow |
| Connection Type | Butt-Weld |
| Radius Type | Short Radius (1×D) |
| Size Range | 1/8” to 4” (DN6 – DN100) |
| Pressure Class | ANSI/ASME B16.9 / Sch. 10 – XXS |
| Material | Carbon Steel, Stainless Steel (304/316), Alloy Steel |
| Manufacturing Process | Hot Closed Die Forging |
| Design Standard | ASME B16.9, ASTM A234 WPB, MSS-SP-75 |
| Testing | Hydrostatic Test, PMI Test, Visual & Dimensional Inspection |
| Surface Finish | Polished, Pickled & Passivated, Black |
Why Choose Flangeman Steel Worldwide Pvt Ltd?
Compact and strong design for tight piping layouts.
High-performance materials for durability and corrosion resistance.
Rigorous quality control including hydrostatic and dimensional testing.
Long service life with minimal maintenance for critical piping systems.
Butt-Weld Short 45° Elbows from Flangeman Steel Worldwide Pvt Ltd combine compactness, reliability, and compliance with global standards, ensuring high performance in demanding industrial environments.
